358 Security Fencing Anti-Climb Anti-Cut Galvanized Steel Panels

CHINA Anping yuanhai wire mesh products Co., Ltd zertifizierungen
CHINA Anping yuanhai wire mesh products Co., Ltd zertifizierungen
Dank für Ihre nett Gastfreundschaft. Ihre Firma ist sehr Berufs, wir sind sehr erfüllt mit Ihrem erweiterten metel Blatt, wir hat die nette Zusammenarbeit in naher Zukunft.

—— Roger Hopkins

Gute Firma mit nettem Service und hohe Qualität und hohes Ansehen. Der EdelstahlMaschendraht ist gute Qualität, eine unseres zuverlässigen Lieferanten, werden Waren in Zeit und in nettes Paket geliefert.

—— Mr.mosharaf-hossain

Empfangene ur Gabions-Masche, Dank für Ihren guten Kundendienst. Ausgezeichnete Trainings- und Technologieunterstützung hilft mir viel.

—— Tshediso Sedie

Ich bin online Chat Jetzt

358 Security Fencing Anti-Climb Anti-Cut Galvanized Steel Panels

358 Security Fencing Anti-Climb Anti-Cut Galvanized Steel Panels

Großes Bild :  358 Security Fencing Anti-Climb Anti-Cut Galvanized Steel Panels

Produktdetails:
Herkunftsort: China
Markenname: YUANHAI
Zertifizierung: ISO9001
Modellnummer: YH-ACF
Zahlung und Versand AGB:
Min Bestellmenge: 100 PCs
Preis: US$20~80
Verpackung Informationen: 1. Blasenwicklung auf der Unterseite der Palette 2. Plastikfolie zwischen die beiden Platten 3. Meta
Lieferzeit: 5-8 Arbeitstage
Zahlungsbedingungen: T/t, l/c
Versorgungsmaterial-Fähigkeit: 500 Prozent pro Monat
Ausführliche Produkt-Beschreibung
Produktname: 358 Sicherheits-Fechten Schlüsselwörter: Antennenhürden
Schweißfestigkeit: Der Bereich 540 ∼ 690 N/m2. Panelhöhe: 1.2m-6m (empfohlene Größe: 2m/2.4m/3m)
Horizontaler Draht: 3,5 mm Anwendung: Hochsicherheitsgebiete
Breite: 2,5 m Material: Verzinkter Stahldraht
Fertig: Galvanisiert, beschichtete das beschichtete Pulver, PVC Sicherheitsstufe: Anti-Climb, Anti-Cut
Verfahren: Gewebe und Schweißen Probe: Kostenlos
Hervorheben:

358 anti-climb security fencing

,

galvanized steel security panels

,

anti-cut 358 fence panels

High Strength 358 Security Fencing Anti-Climb Protection Panels
Product Specifications
Attribute Value
Product Name 358 Security Fencing
Key Features Anti-climb, anti-cut fence
Welded Strength 540–690 N/m²
Panel Height 1.2m-6m (Recommended: 2m/2.4m/3m)
Horizontal Wire 3.5mm
Application High security areas
Width 2.5m
Material Galvanized steel wire
Finishing Galvanized, powder coated, PVC coated
Security Level Anti-Climb, Anti-Cut
Process Weaving and Welding
Sample Available for free
Product Description

The 358 security mesh is the ultimate security fencing system, also known as the wire-wall system. Its design makes it extremely difficult to cut through using conventional wire cutters, offering maximum security and anti-corrosion protection.

With its 4mm wire diameter and rectangular mesh configuration, the panel provides excellent visibility while resisting vandalism. The finger and toe-proof mesh pattern classifies it as an anti-climb system, making it ideal for high-risk areas. This system is extensively used by the Ministry of Defence around high-security sites.

The mesh size is 76.2×12.7mm (center to center), with horizontal wire spacing of 12.7mm and vertical wire spacing of 76.2mm. The fencing offers superior anti-corrosion performance, anti-aging properties, aesthetic appeal, and easy installation.

Detailed Specifications
Specification 2.1m 2.4m 3.0m
Panel height 2134mm 2438mm 2997mm
Panel width 2515mm 2515mm 2515mm
Mesh size 12.7 x 76.2mm 12.7 x 76.2mm 12.7 x 76.2mm
Horizontal wire 4mm 4mm 4mm
Vertical wire 4mm 4mm 4mm
Panel weight 50kg 57kg 70kg
Posts 60 x 60 x 3 mm 60 x 60 x 3 mm 80 x 80 x 3 mm
Post length 2.8m 3.1m 4.0m
Clamp bar 40 x 6 m slotted 40 x 6 m slotted 40 x 6 m slotted
Fixings 8 galv bolt c/w Permacone security nut
No. of fixings 8 9 11
Key Features
  • Anti-climb: The high-density mesh makes it impossible to grasp with hands and feet, providing excellent protection against climbing.
  • Anti-shear: Large wire diameter and dense mesh configuration render conventional wire cutters ineffective.
  • Aesthetic appeal: Flat mesh surface with high visibility and vandalism resistance.
Applications
Prisons
Sport Stadiums
Schools/Hospitals
Commercial Sites
Airports
Power stations
Industrial Estates
358 Fence Panel Types
358 Security Fencing Anti-Climb Anti-Cut Galvanized Steel Panels 0 358 Security Fencing Anti-Climb Anti-Cut Galvanized Steel Panels 1
Packaging
358 Security Fencing Anti-Climb Anti-Cut Galvanized Steel Panels 2 358 Security Fencing Anti-Climb Anti-Cut Galvanized Steel Panels 3 358 Security Fencing Anti-Climb Anti-Cut Galvanized Steel Panels 4
